Double-lead worm gear facilitates easy adjustment.
Hydraulic clamping for secure locking.
Curvic coupling positioning with high accuracy of 1° per minute.
Bidirectional electronic control for reliable operation.
Technical Parameter
| ITEM | UNIT | HRT-1000KZT | |
| Pallet Dimension | mm | 1000×1000 | |
| Spindle Hole Diameter | mm | Ø60H7 | |
| Overall Height | mm | 380 | |
| Servo Motor | Fanuc | — | αiF12 / β22 |
| Siemens | — | 1FK7084 | |
| Meldas | — | HF-303S | |
| Speed Reduction Ratio | — | 1-180 | |
| Minimum Indexing | deg. | 1° | |
| Max Speed of Pallet Top | — | 16.66 | |
| Indexing Accuracy | arcsec | 10 | |
| Repeatability Accuracy | arcsec | 2 | |
| Clamping Torque | kgf-m² | 1820 | |
| Suitable Environment Temperature | ℃ | 18°~40° | |
| Permissible Cutting Force | kgf-m² | 1275 | |
| Max. Load | kg | 5000 | |
| Net weight | kg | 1150 | |
