● Dual-lead worm and worm gear for easy adjustment;
● Hydraulic clamping for secure locking;
● Indexing at any angle, suitable for simultaneous machining.
Technical Parameter
| ITEM | UNIT | HRT-1200ZT |
| Pallet Dimension | mm | 1200×1200 |
| Spindle Hole Diameter | mm | ø140H7 |
| Overall Height | mm | 435 |
| Servo Motor (Fanuc) | FANUC | ais30 |
| Servo Motor (Siemens) | SIEMENS | / |
| Servo Motor (Meldas) | MELDAS | / |
| Speed Reduction Ratio | — | 0.291666667 |
| Minimum Indexing | degree | 0.001° |
| Max Speed of Pallet Top (r/min) | r/min | 2 |
| Indexing Accuracy | arcsec | 15 (±5) |
| Repeatability Accuracy | arcsec | 4 |
| Clamping Torque (5kg/cm, kgf-m²) | kgf-m² | 8000 |
| Suitable Enviroment Temperature | ℃ | 18° ~ 40° |
| Permissible Cutting Force | kgf-m² | 500 |
| Max. Load | kg | 12000 |
| Net weight | kg | 2600 |
