● Double-lead worm gear for easy adjustment;Hydraulic clamping for secure locking;
● Curvic coupling indexing with high positioning accuracy of 1° per division;
● Bidirectional electronic control for reliable operation.
Technical Parameter
| ITEM | UNIT | HRT-400 | |
| Pallet Dimension | mm | 400x400 | |
| Spindle Hole Diameter | mm | 30H7 | |
| Overall Height | mm | 240 | |
| Servo Motor | Fanuc | FANUC | ais8 |
| Siemens | SIEMENS | 1FK7063 | |
| Meldas | MELDAS | HF-154S | |
| Speed Reduction Ratio | 1:120 | ||
| Minimum Indexing | degree | 1° | |
| Max Speed of Pallet Top | 16.6 | ||
| Indexing Accuracy | arcsec | 4 | |
| Repeatability Accuracy | arcsec | ±1 | |
| (50kg/cm) kgf-m2 Clamping Torque | 200 | ||
| Suitable Enviroment Temperature | ℃ | 18°~40° | |
| Permissible Cutting Force | kgf-m2 | 78 | |
| Max. Load | kg | 350 | |
| Net weight | kg | 205 | |
