Double-lead worm gear for easy adjustment;Hydraulic clamping for secure locking;
Curvic coupling indexing with high positioning accuracy of 1° per division;
Spring return mechanism with unidirectional control;
Technical Parameter
| ITEM | UNIT | HRT-630 |
| Pallet Dimension | mm | 630×630 |
| Spindle Hole Diameter | mm | Ø55H7 |
| Overall Height | mm | 330 |
| Servo Motor - Fanuc | — | αiF12 |
| Servo Motor - Siemens | — | 1FK7083 |
| Servo Motor - Meldas | — | HF-204S |
| Speed Reduction Ratio | — | 0.125 |
| Minimum Indexing | deg. | 1° |
| Max Speed of Pallet Top | — | 16.66 |
| Indexing Accuracy | arcsec | 10 |
| Repeatability Accuracy | arcsec | 2 |
| Clamping Torque | kgf-m² | 860 |
| Suitable Enviroment Temperature | ℃ | 18°~40° |
| Permissible Cutting Force | kgf-m² | 650 |
| Max. Load | kg | 2500 |
| Net weight | kg | 650 |
