Double-lead worm gear for easy adjustment;
Hydraulic clamping for secure locking;
Curvic coupling indexing with high positioning accuracy of 1° per division;
Technical Parameter
| ITEM | UNIT | HRT-800APC | |
| Pallet Dimension | mm | 800×800 | |
| Fixed Hole Diameter | mm | 24-M16 | |
| Overall Height | mm | 640 | |
| Servo Motor | Fanuc | FANUC | αiF12/β12is |
| Siemens | SIEMENS | 1FK7083 | |
| Meldas | MELDAS | HG-204 | |
| Speed Reduction Ratio | — | 0.173611111 | |
| Minimum Indexing | degree | 1° | |
| Max Speed of Pallet Top | — | 15 | |
| Indexing Accuracy | arcsec | 10 | |
| Repeatability Accuracy | arcsec | 2 | |
| (50kg/cm) kgf-m² Clamping Torque | kgf-m² | 1820 | |
| Suitable Environment Temperature | ℃ | 18° ~ 40° | |
| Permissible Cutting Force | kgf-m² | 1275 | |
| Max. Load | kg | 2000 | |
| Net weight | kg | 1050 | |
